1. Check the cleanliness of the fiber laser pipe cutter protective lens:
Please clean the fiber laser pipe cutting machine that is not clean in time; please replace the protective lens that has a burning point and will affect the use in time. (Note: When taking out the pipe fiber laser cutting machine protective mirror drawer, ensure that there is no dust on the site, and use masking paper or special plugs in time to effectively seal the protective mirror window).
2. Check the copper nozzle of fiber laser pipe cutting machine:
The copper mouth of fiber laser pipe cutting machine is irregular, and it is recommended to replace it in time if there are obvious scars. Every time you replace the fiber laser pipe cutter copper nozzle, you need to use the floating head to calibrate and check its center. Avoid coaxial deviation or incorrect air flow due to this reason, which will affect the pipe fiber laser cutting machine cutting effect.
3. Check whether the pipe fiber laser cutting machine ceramic ring is loose:
Loose pipe fiber laser cutting machine ceramic ring will affect the stability of fiber laser pipe cutter cutting operation, please tighten the ceramic ring locking ring by hand.
4. Check the center of the fiber laser pipe cutter cutting head:
To ensure the coaxiality of the fiber laser pipe cutter laser head, use scotch tape to adjust, and try to use a small nozzle (such as 1.0), which is more accurate.
5.Fiber laser pipe cutting machine capacitance calibration:
Start the Fiber laser pipe cutting machine every day to perform capacitance calibration, tools-height controller monitoring-F1-2.
6. Return to the origin and calibrate the B-axis center of pipe fiber laser cutting machine:
Turn on the pipe fiber laser cutting machine every day to perform back-to-origin action and calibrate the center of the B-axis.
7. Check the fiber laser pipe cutter air source:
Check whether the remaining air of the fiber laser pipe cutter air source is sufficient for production, and whether there is any air leakage in the air circuit. Check the outlet pressure value of the air storage tank before shift every day, and drain the air storage tank.
8. Clean the chuck of Fiber laser pipe cutting machine:
Clean the dust and iron filings in the chuck of Fiber laser pipe cutting machine with clean compressed air after each shift and lubricate the organ cover.
9. Clean up the suction pipe of pipe fiber laser cutting machine:
Check the pipe fiber laser cutting machine vacuum tube daily for damage and looseness.
The above are the matters needing attention in the daily maintenance of fiber laser pipe cutter, I hope it will be helpful to everyone.
